Ceramic Membrane
- Ceramic membranes are plate-type filter materials with an asymmetric microporous structure, made by sintering aluminum oxide, titanium oxide, zirconia, and catalytic nanomaterials at high temperatures. With high filtration precision, excellent physical strength, and chemical stability, they improve membrane flux and reduce maintenance costs.
Features & Advantages
-
01
Enhanced durability
(Service life of 10 years
or more under general conditions) -
02
High Flux
(25 LMH or more
in wastewater MBR processes) -
03
Strong fouling resistance
(Excellent membrane
regeneration performance) -
04
Easy installation & maintenance
(Convenient modular structure) -
05
Excellent physical & chemical performance
(Corrosion resistance, hydrophilicity)
Ceramic Membrane Module
| Model | M25-U1 | M50-U1 | M200-U1 | M200-U2 |
|---|---|---|---|---|
| Module structure |
|
|
|
|
| Number of membranes (pcs) | 25 | 50 | 200 | 400 |
| Effective membrane area (m²) | 12.5 | 25 | 100 | 200 |
| Module frame size W * D * H (mm) |
650 * 370 * 1750 | 1050 * 370 * 1750 | 2120 * 780 * 1750 | 2120 * 780 * 3300 |
| Dry/wet weight (kg) | 120/180 | 204/319 | 631/831 | 1209/1609 |
| Module frame material | 304 stainless steel | |||
Applications
-
Water treatment
Water & wastewater treatment
and industrial water management -
Chemical industry
Process water and
wastewater treatment -
Food & beverage
Product purification
and quality control -
Pharma / Bio
High-purity water and
separation processes
-
01 Sewage & wastewater treatment
Advanced treatment processes, industrial complex wastewater and industrial water reuse, domestic sewage, and graywater recycling systems
-
02 Industrial process water treatment
Pre-treatment of semiconductor/display rinse water, purification of steel and petrochemical process water, and pre-treatment for ultrapure water in pharma/bio industries
-
03 Non-point source & natural water purification
Water quality improvement for golf courses, lakes, and ponds; purification of agricultural and livestock water; rainwater and runoff treatment
